Medi-6000 Plus

Chest X- Ray Film : 12 Seconds

  • 4.0 Dmax, 600 dpi optical resolution (42 µm spot size, 12 lp/mm)
  • Covers various sizes of X-Ray Films from 2.5″x 2.5″ to 14″x 35″
  • LED, Auto-Crop & Auto-Deskew
  • TWAIN, 8/16 bit Gray
  • Automatic Film Feeder with 15-page capacity (optional)
  • Supports DICOM 3.0 and Telemedicine with optional MiPAX
  • FDA certified

Professional Digitiser for Medical Archives & Hospitals

Download Brochure       Get Price Quote



Description

Microtek medical grade digitizer, the Medi-6000 Plus, can digitize X-Ray films rapidly in 12 seconds per chest X-Ray. With the advanced technology of the LED light source, the Medi-6000 Plus can reach full brightness and on/off operation immediately.

The Medi-6000 Plus can scan various sizes of X-Ray films up to 14×35 inches, letting user easily archive many kinds of X-Ray films. Equipped with high optical resolution, excellent Dmax, and 16-bit grayscale, the Medi-6000 Plus provides great image quality at an affordable price. It is easy to operate, clean, and maintain.

With the optional MiPAX systems of DICOM ready function, Medi-6000 Plus is perfect for fast-paced environment of the medical doctor’s office, QC Station and PACS system.

Microtek Bio-5000 Plus

Auto Film Feeder with 15-sheet capacity (optional)

12 seconds per Chest X-Ray.

Microtek medical grade digitizer, the Medi-6000 Plus, can digitize X-Ray films rapidly in 12 seconds per chest X-Ray ( Gray, 300 dpi ).

No warm up time with LED light source.

Adopting LEDs as the light source, there are no requirements for any warm-up time before carrying out the scan, which boots your productivity and reduces energy costs amazingly. With its stable performance, the image quality will remain consistent.

Archives X-Ray films from 2.5”x2.5” to 14”x35”.

4.0 Dmax, 600 dpi optical resolution

Supports DICOM 3.0 and telemedicine with optional MiPAX

Additional information

Product Name

Medi-6000 Plus

Scanner Type

X-Ray films,
Sheet-fed digitizer

Image Sensor Type

CCD

Resolution

600 dpi (42 um spot size, 12 lp/mm)

Light Source

LED

Scanning Area

Film Scan Area
Min: 2.5” x 2.5”(63.5 x 63.5 mm)
Max: 14” x35”(355.6 x 889 mm)

Scanning Speed

12 seconds,@ 300 dpi, 14” x 17”

Dynamic Range

Transparency 0.12D~3.7D, 4.0Dmax

Bit Depth

8/12/16-bit grayscale

Connectivity

Hi-Speed USB (USB 2.0)

Drivers

TWAIN

Scanable Media Types

Transparent

Supported File Types

TIF, BMP, EPS, JPG, PSD, SCT, GIF, IFF, PCX, PXR, TGA, PDF, DCX

Supported Film Types

Min: 2.5” x 2.5”(63.5 x 63.5 mm)
Max: 14” x35”(355.6 x 889 mm)

OS Support

Windows XP/ Vista/ Windows 7/ Windows 8 (ScanWizard Medi)

Dimensions (L x W x H)

590 x 483 x 307 mm (with tray)

Weight

19.18 lbs (8.7 kg)

Certifications

CE0120, FDA, CFDA, TFDA(003518), CCC

Power Source

AC 100V ~ 240V, 47 ~ 63 Hz

Power Consumption

54.9 Watts

System Requirements PC

CD-ROM drive (for installing software)
2 GB RAM or more
Pentium IV PC or higher with USB port
Microsoft Windows XP/ Vista/ Windows 7

Inbox Contents

Digitizer unit
Power adapter & power cord
High-Speed USB 2.0 cable
CD(s)
Manual(s)

Software Included

Microtek ScanWizard Medi
Adobe Acrobat Reader

Accessories

Microtek MiPAX-Xray software (Optional)
Automatic Film Feeder (Optional) : Up to 15 pics of film (Min. 2.5”x10” / Max. 14“ x 17”)
