Bookeye 5 V2

BPO Favourite, Large 18″ X 24″

  • Colour Overhead Scanner for Formats up to A2+
  • Exceeds FADGI ** Guidelines, ISO 19264-1
  • 400 x 400 DPI / 600 x 600 DPI Scanner Resolution
  • V-Shaped Book Cradle 120 – 180 degrees
  • Optional V-Shaped Glass Plate
  • Auto Format, Auto Scan, Auto Focus, Auto Crop
  • Book Fold Correction, Thumb Removal
  • Built in Processing, Live Preview Monitor

Land Registration Projects, Archives, Production/Bulk Scanning

Download Brochure       Get Price Quote





Category: Tags: ,

Description

Bookeye® 5 V2 Overhead Book Scanner

Bookeye® 5 V2 has been fully redesigned to be even more eco-friendly, ergonomic and easy to operate than the previous Bookeye 4 models. Bookeye 5 V2 offers maximum efficiency throughout the entire scanning process. Its modular product concept enables an easy upgrade from the Basicmodel to the Kiosk version or to the Professional version, depending on your budget and scanning requirements.

The Bookeye 5 V2 book scanner now scans faster and delivers the highest quality image results, while offering smart, new functionality.  It is a true scanner solution, not just a digicam mounted on an expensive frame. It was specifically designed as a self-service book scanner for formats 14 % larger than A2 (460 x 620mm / 18 x 24 inch), intuitive built in operating system.

Installation is so simple, you will be scanning within minutes after taking it out of the box. The Bookeye 5 V2 is perfect for libraries, archives, offices and anywhere you want to scan and copy.

Three book scanner models available: Basic, Kiosk and Professional

The entry level model offers the same scanning functionality and speed as the other levels at the lowest possible cost.
This model includes all of the features of the Basic model plus the Scan2Pad application for scanning and operation with any mobile device, foot switch and Full Coverage Warranty.
This model includes all of the features of the Basic model, but has a higher resolution of 600 dpi and client interface for 3rd party software to meet the highest quality standards. It also includes a foot switch and Full Coverage Warranty.



21 inch full HD multitouch screen allows the operator to control image quality and make many modifications on the fly.  Pinch and swipe on the touchscreen the same way you would on a smartphone to zoom or move around in the image during preview. Attach a second, optional screen to operate the scanner with the main touchscreen and preview images using the second screen.  TheLive Preview function uses a second matrix camera to present a live video view of the document position before scanning.



There are three possible positions to attach the touchscreen: attached to the scanner neck, attached to the side of the scanner closer to the front or attached to the side of the scanner closer to the back, where you can angle the monitor in various degrees. It can also be used unattached, lying flat next to the scanner. The picture above shows the three attached positions.

Optionally a separate preview screen can be mounted to the neck, if the main touch is on the side.

The unique magnetically coupled book cradle solution allows users to digitize books and documents A2+ in size, by either laying them flat on the scanning bed at 180°or in the V-cradle, at an angle of 120° for gentle, protective handling of the source material. The two sides of the cradle are magnetically coupled so that the book fold can be moved easily in the center for optimal scan results.

Dark mode operation, new to the Bookeye 5 V2 book scanner, enhances scan quality through less light reflection and improves operation by reducing eye strain.

Multilingual operation, with over 20 languages available for the unique Scan2Net and ScanWizard user interfaces. Customize the interfaces to comply with corporate identity norms and standards.

Laser-assisted book fold correction effectively reduces annoying shadows and distortions in the middle of a scanned image of a book when operators are scanning thick bound documents, resulting in a perfectly flat scanned image.

Bookeye® 5 V2 Kiosk with Scan2Pad®

The Bookeye 5 V2 Kiosk book scanner is an extended version of the Bookeye 5 V2 Basic book scanner and includes the Scan2Pad functionality, enabling wireless connection of the Bookeye  5 V2 Kiosk directly to mobile devices like iPads and Android tablets.  Operate the book scanner directly from your mobile device and the scanned images are available immediately as PDF or JPEG files. Automatic size recognition of the source material, color, grayscale and bitonal scanning, all with high quality image results, are just some of the features of the Bookeye 5 V2 Kiosk book scanner.

Bookeye® 5 V2 Kiosk can do the accounting for you!

The Bookeye 5 V2 Kiosk book scanner has an optional integrated billing module. For all applications that do not have an existing card or billing system, Bookeye 5 V2 Kiosk can take over the billing itself. Configurable invoice printing and journaling, and the remote locking / unlocking of the system are standard functions in the Bookeye 5 V2 Kiosk.

Bookeye® 5 V2 Professional for 600 dpi resolution + Client Interface

The Bookeye5 V2 Professional book scanner extends the Basic model to 600 dpi resolution for projects and applications which demand the highest quality image results.The client interface enables simple integration of complex workflows utilizing one of the many capturing software solutions available, such as BatchScanWizard or BCS2.

Bookeye® 5 V2 Book Scanner Functions

  • Color overhead scanner for A2+ formats
  • High resolution line sensor with 400 x 400 dpi scanner resolution  (600 x 600 dpi optional)
  • Maximum Document Size 460 x 620 mm (18 x 24 inch)
  • Operation in dark mode enhances scan quality and improves operation through less light reflection
  • Live preview function shows the document position in live video for optimal placement
  • Magnetically coupled V-shaped book cradles 120 – 180 degrees
  • Laser assisted book fold correction – Scan bound documents without annoying shadows
  • Optimize images without rescanning, real time display of scanned images
  • Automatic finger and thumb removal
  • Automatic Crop & Deskew
  • Digital color balance – wide color gamut: supports sRGB, Adobe RGB, native RGB
  • Automatic white balance and black value
  • Scan2USB — Direct output to the integrated USB-Port
  • Scan2Net® — Output to SMB, FTP, Printer, Email
  • Output formats: Multipage PDF (PDF/A) &TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
    TIFF (Raw, G3, G4, LZW, JPEG) and many more

Bookeye® 5 V2 Book Scanner Features

  • Easy three button operation: Start — Scan — Send
  • 2 x USB 3.0 port accessible on the front panel
  • Large 21 inch full HD  color multitouch screen for simplified operation, 2nd preview screen optional
  • Smallest possible footprint, sits on any desktop or workspace
  • User interface configurable in over 20 languages
  • Intel Quad Core i3 Gen.8 240 GB SSD, 8GB RAM
  • LED lamps, no warm up, IR/UV free
  • Can be used as a standalone device without an external PC
  • Virus protected 64 bit Linux operating system
  • OS independent, runs with Windows 8, 10, Linux, Mac
  • Uses any browser: IE, Safari, Chrome, Firefox
  • Scan2Net® technology
  • Complies to FADGI *** guidelines, Metamorfoze Light and ISO 19264-1
  • Remote maintenance and analysis
  • Simple installation – scan minutes after taking it out of the box

Bookeye® 5 V2 Book Scanner Options

  • BE5-SCAN2PAD — Scan2Pad® wireless hotspot
  • BE5-V2-PRO-OPT — Upgrade to Professional, Client Interface & 600 dpi
  • BSW-P-BE5-01 * — Batch Scan Wizard Pro License for Bookeye 5 V2
  • BE-TWAIN * — TWAIN driver
  • S2N-FSC — Foot Switch, hardware accessory for batch scanning
  • Scan2OCR — Background OCR option for Scan2Net scanners (Only in connection with Batch Scan Wizard)
  • Scan2ICC — Subscription for ICC color management and profiles
  • BE5-V2-BK-SP12M — Full Coverage Warranty for one year– Up to 5 years subscription available

* only with the option: Client Interface & HD 600 dpi

Additional information

Maximum Document Size

460 x 620 mm (18 x 24.4 inches),
14% > DIN A2

Scanner Resolution

600 x 600 dpi

Pixel Dimension

9.3 x 9.3 µm

Scan Speed Color

DIN A2+ @ 150 dpi: 0.9 s
DIN A2+ @ 200 dpi: 1.1 s
DIN A2+ @ 300 dpi: 1.6 s
DIN A2+ @ 400 dpi: 2.0 s
DIN A2+ @ 600 dpi: 3.0 s

Color Depth

48 bit color, 16 bit grayscale

Scan Output

24 bit color, 8 bit grayscale, bitonal, enhanced halftone

File Formats

Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu,
DICOM, PCX, Postscript, EPS, Raw data

ICC Profiles

Embedded for sRGB, Adobe RGB and native. Individual profiling via web based Scan2ICC subscription

Quality

Exceeds FADGI ** guidelines, ISO 19264-1

Computer

64 bit Linux, Intel i3, quad core processor,
8 Gigabyte RAM, 320GB HDD for extra large jobs

Touchscreen

7 inch color WVGA (wide VGA) touchscreen

Monitor

22 inch touchscreen

USB Port

2 USB Ports 3.0

Interface

1 GBit Fast Ethernet with TCP/IP based Scan2Net® interface

Camera

CCD camera

Light Source

White LEDs, tested according to IEC 62471, no IR/UV emission
Declaration about the Emission of UV and IR radiation

Lamp Life Time

50,000 h (typ.)

Dimensions Scanner (H x W x D)

780 x 670 x 740 mm (30.7 x 26.4 x 29.1 inches)

Weight Scanner

52.5 kg (116 lbs.)

Electrical Connection

100-240 V AC, 47 – 63 Hz (external power supply,
complies with ECO standard CEC level VI)

Power Consumption

< 0.5 W (Sleep) / 2.5 W (Standby) /
75 W (Ready to scan) / 130 W (Scanning)

Operating Temp

5 to 40 °C (40 to 105 °F)

Rel Humidity

20 to 80 % (non-condensing)

Noise

< 42 dB(A) (Scanning) / < 33 dB(A) (Standby)
