WideTEK 48CL

Wide Format, Sheet Feed, High Speed Scanners

  • Scans 48 inch widths, nearly unlimited length
  • Exceeds FADGI *** guidelines, ISO 19264-1
  • Fastest color scanning at 10 inches per second (15 m/min) @ 150 dpi
  • 1200 x 1200 DPI Scanner Resolution
  • Automatic Crop & Deskew

World’s only Duplex A0 Scanner for Newspaper

Download Brochure     Get Price Quote



Description

Production Quality Scanner, Made in Germany

The WideTEK® 48CL-600 is by far the fastest 48 inch color CIS scanner on the market, producing production quality images at 10 inches per second for 150 dpi in full color. At the full width of 48″ and 1200dpi resolution, the scanner still runs at 0.83 inches per second. The scanning speeds are tripled in black and white and greyscale modes but the speed can be limited if required to scan fragile, valuable documents.



All of these speeds are guaranteed, due to the Scan2Net® technology integrated in the scanner´s own built in 64 bit Linux PC and 16GB of memory. It is a true standalone system capable of scanning directly to FTP servers, hot folders, USB drives, to cloud applications in the internet or copying to printers directly, without the need for an extra PC. The WideTEK® 48CL has what it takes to run in a production environment 24/7, while still being among the lowest priced scanners of its size on the market.

Through reengineering and utilizing the most advanced CIS modules, the WideTEK 48CL is truly the fastest CIS scanner available. Document rotation is done on the fly, a scan of an E-sized / A0 document in landscape at 300 dpi in 24bit color takes less than 7 seconds to scan and another 1,5 seconds to crop & deskew, preview, cleanup, compress and store anywhere in the network. The WideTEK 48CL exceeds FADGI *** guidelines and complies with the ISO 19264-1 standard.

The WideTEK® 48CL processes documents up to 50 inches wide with a maximum scanning width of 48 inches, producing extraordinarily sharp images, with color accuracy even superior to competing CCD scanners. Document rotation is done on the fly, a scan of an E-sized / A0 document in landscape at 300 dpi in 24bit color takes less than 7 seconds to scan and another 2 seconds to crop & deskew, preview and store.

WideTEK® 48CL Functions

  • Scans 48 inch widths, nearly unlimited length
  • Exceeds FADGI *** guidelines, ISO 19264-1
  • Fastest color scanning at 10 inches per second (15 m/min) @ 150 dpi
  • 1200 x 1200 dpi scanner resolution
  • Automatic crop & deskew
  • On the fly rotation while scanning facilitates postprocessing
  • Face up scanning (no more “blind” scanning)
  • Real time display of scanned images, modify images without rescanning
  • Standalone device with its own Linux PC
  • Scan2USB — Walk up Scanning to any USB device via USB 2.0
  • Scan2Print — Copy to networked printers or hot folders
  • Scan2Network — Output to network resources, SMB, FTP
  • Output formats: PDF, PDF/A, JPEG, TIFF, PNM, multipage PDF and TIFF, DICOM and many more
  • Scan2Pad® — Operation via tablet, smartphone or other mobile device

WideTEK® 48CL Features

  • LED lamps, no warm up, IR/UV free
  • Large color WVGA touchscreen for simplified operation
  • User interface configurable in your language
  • Virus resistant Linux OS
  • OS independent, runs with Windows 7, 8, 10, Linux, Mac
  • ScanWizard uses any browser: IE, Safari, Chrome, Firefox
  • Integrated walk up scanning software
  • Use touchscreen enhanced versions of ScanWizard, PrintWizard and EasyScan with Scan2Net firmware version 6.30 and later with a full HD external touchscreen and view your scan results in high definition.
    Download the HD Touchscreen brochure here.
  • Easy installation via Scan2Net® Technology
  • Remote maintenance and troubleshooting
  • Firmware updates via web interface
  • Dust-free camera technology

WideTEK® 48CL Options

  • Transparent document carriers for fragile document handling, available in two sizes: A0 and A1
  • Foot Switch — Hardware option for batch scanning
  • WideTEK — UMFS universal multifunction stand, external 22″ touchscreen for virtual rescans
  • Batch Scan Wizard — Software option for high volume scanning
  • Scan2iPF — Software option for direct and fast copy to imagePROGRAF
  • Scan2EDIT — Software option for scanning and image processing in a single step
  • Scan2ICC — Subscription for ICC color management and profiles
  • TWAIN Interface — Software interface option
  • Extended resolution — Extend the resolution to 9600 dpi
  • Full Coverage Warranty — Up to 5 years subscription for full coverage warranty package and free spare parts

Additional information

Maximum Document Size

1270 mm (50 inches)

Maximum Scan Width

max. 1220 mm (48 inches)

Document Thickness

max. 2.5 mm (0.1 inch)

Autoformat Size Recognition

yes, crop & deskew

DIN Format

DIN A5 – DIN A0

ANSI Format

Legal, US E

Scanner Resolution

1200 x 1200 dpi (optionally 9600 x 9600 dpi interpolated)

Pixel Dimension

42 x 42 µm

Paper Path

Face up, Front entry, Front or rear exit

Scan Speed Color

200 dpi – 11.4 m/min (7.5 inch/s)
300 dpi – 7.6 m/min (5 inch/s)
600 dpi – 2 m/min (1.3 inch/s)
1200 dpi – 0.9 m/min (0.6 inch/s)

Scan Speed BW

200 dpi – 22.9 m/min (15 inch/s)
300 dpi – 22.9 m/min (15 inch/s)
600 dpi – 5.8 m/min (3.8 inch/s)
1200 dpi – 2.9 m/min (1.9 inch/s)

Color Depth

48 bit color, 16 bit grayscale

Scan Output

24 bit color, 8 bit grayscale, bitonal, enhanced halftone

File Formats

Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu,
DICOM, PCX, Postscript, EPS, Raw data

ICC Profiles

Embedded for sRGB, Adobe RGB and native. Individual profiling via web based Scan2ICC subscription

Quality

Exceeds FADGI *** guidelines, ISO 19264-1

Scan direction

± 0.08% across 36 inch scanning width

Transport direction

± 0.08% with new transport rollers

Computer

64 bit Linux, Intel quad core processor,
8 Gigabyte RAM, 128GB SSD for very long scans

Touchscreen

7 inch color WVGA (wide VGA) touchscreen

Monitor

22 inch touchscreen with arm (included in the bundle)

USB Port

1 USB Port 3.0

Interface

1 GBit Fast Ethernet with TCP/IP based Scan2Net® interface

Camera

4x CIS modules, 29,852 pixels, encapsulated and dust-proof

Light Source

RGB LED
Declaration about the Emission of UV and IR radiation

Dimensions Scanner (H x W x D)

170 x 1418 x 358 mm (6.7 x 55.8 x 14.1 inches)

Weight Scanner

28.5 kg (63 lbs.)

Electrical Connection

100-240 V AC, 47 – 63 Hz (external power supply,
complies with ECO standard CEC level VI)

Power Consumption

< 0.5 W (Sleep) / approx. 5 W (Standby) /
< 25 W (Ready to scan) / < 45 W (Scanning)

Operating Temp

5 to 40 °C (40 to 105 °F)

Rel Humidity

20 to 80 % (non-condensing)

Noise

< 35 dB(A) (Scanning) / < 25 dB(A) (Standby)
